BK8000L Wireless bluetooth Stereo Audio Module Transmission AT Commands SPP bluetooth Speaker
Tax included.
Munual: http://myosuploads3.banggood.com/products/20190117/20190117031219SKU480603.docx
Specification:
1.Model:BK8000L
2.Name:F-6188 V4.0
3.bluetooth :V2.1+EDR
4.Supply voltage :DC2.8-4.2V
5.bluetooth protocol: HFPV1.5, A2DPV1.2, AVRCPV1.4, HSP1.2, GAVDP1.2, IOP
6.Working current :≤45mA
7.Standby current :<500uA
8.Temperature range: -40°C ~ + 85°C
9.Wireless transmission range: >10 meters
10.Transmission power :Class2, 4dbm
11.Sensitivity :-80dBm <0.1% BER
12.Frequency Range :2.4GHz ~ 2.480GHz
13.Decoding audio performance:SBC
14.SNR:≤75db
15.Board size 25x13.5mm
,
,
,
,
,
,
,
Specification:
1.Model:BK8000L
2.Name:F-6188 V4.0
3.bluetooth :V2.1+EDR
4.Supply voltage :DC2.8-4.2V
5.bluetooth protocol: HFPV1.5, A2DPV1.2, AVRCPV1.4, HSP1.2, GAVDP1.2, IOP
6.Working current :≤45mA
7.Standby current :<500uA
8.Temperature range: -40°C ~ + 85°C
9.Wireless transmission range: >10 meters
10.Transmission power :Class2, 4dbm
11.Sensitivity :-80dBm <0.1% BER
12.Frequency Range :2.4GHz ~ 2.480GHz
13.Decoding audio performance:SBC
14.SNR:≤75db
15.Board size 25x13.5mm
Package Included :
1 x BK8000L bluetooth Stereo Audio Module
,,,,,,,
