HIFI DAC Audio Expansion Board PCM5122 Chip for Raspberry 3 Model B+/3B
Tax included.
Specification:
Color: Green
Type: For Raspberry Pi 3 Model B+ / 3B
Features:
• HAT size
• DAC SNR is 112Db
• DAC THD+N at -1 dBFS -78dB
• Full Scale Output of DAC is 2.1Vrms
• Dynamic Range of DAC is 112dB
• Sampling Frequency ranges from 8kHz to 384kHz
• Ultra-low noise voltage regulators for optimal audio performance
• Integrated EEPROM for automatic configuration (option)
• Automatically switching frequencies according to the input I2S signals
• Dual low jitter crystal oscillators for Master Clock generation
• Infrared remote control connector (using GPIO26)
• DAC output coupled with Film capacitor
• Dedicated 384kHz/32bit high-quality DAC PCM5122 for best sound quality
• Audio output connectors: 2x RCA (LEFT &Right) &3.5mm head phone Jack
• With 138mw headphone Amplifier can directly drive headphone
• Work status indicators facilitate the understanding of the system working status
Hardware Connection:
Connect the RPI-HIFI-AMP module and RPI with 40 pin connector. While installing the module attention to align the first leg of the raspberry pi and RPI-HIFI-DAC module.
Software Installation:
RPI-HIFI-DAC module compatible with many Raspberry pi music playback system such as:
OSMC / Max2Play / RuneAudio / Volumio / Moode / PiCorePlayer / PiMusicBox / OpenELEC etc.
(The user can choose a suitable for their own.)
Reference Link:
http://www.raspberrypiwiki.com/index.php/RPI_HIFI_DAC
Package Included:
1 x RPI HIFI DAC Board
1 x Screw Package
(NOT included Raspberry Pi motherboard)
Instruction is not included. Any questions, please contact us immediately for solution. Hope a nice day!
