3pcs 3S 12V 8A Li-ion 18650 Lithium Battery Charger Protection Board 11.1V 12.6V 10A BMS Charger Protection Board
Tax included.
Description:
3 series (for three 18650 batteries or polymer lithium battery series combination)
The rated voltage of 10.8 V (polymer battery)
18650 or 11.1 V (nominal voltage of 3.7 V lithium battery)
12.6 V voltage after a full battery (lithium)
8 a discharge (refers to the maximum discharge current limit)
Specifications:
Model: HX-3S-A02
Size: 51 * 10 * 3.0MM
The maximum working current: 3-4A
Maximum instantaneous current: 7-8A
Static electricity: less than 10UA
Resistance: less than 60 mΩ
Charging voltage range: 4.25-4.35V + / - 0.05V
Discharge voltage range: 2.3-3.0V + / - 0.05V
Working temperature: - 40 - + 50 °
Storage conditions: - 40 - + 80 °
Short circuit protection, can protect, delay the recovery
Note:
This cannot be used for iron from polymer battery protection board, hand electric drill battery, electric fish electromechanical ChiZu, electric bicycle batteries, 2 piece series 24 v, 775 (4 a) above, electrical fisheye 1 w LED lamp, used for the combined purchase customers please note!
Applications:
Described within the scope of power is suitable for the following products:
Massager battery back-up power, LED lamp, 12 v electronic products, battery pack, monitoring standby power, solar street lamps and other products.
Note: more than 3 a current discharge products, battery discharge rate is more than 3 c.
Ratio calculation formul a: 1 c rate of the battery, 2000 capacity is equal to 2 ah * 1 = 2 a maximum working current.
3 c ratio battery, 2000 capacity is equal to 2 ah * 3 = 6 a maximum working current.
In use battery heats is ratio is not applicable, this situation must not be used for a long time, the battery will soon be damaged.
Package Included:
3 x 3S 12V 8A Li-ion 18650 Lithium Battery Charger Protection Board
