Minleaf 3000W Solar Power Inverter 12V To 220V Modified Sine Wave Inverter Car AC Converter 8 Protection

Specification:


Brand	Parameter	Minleaf	Note
Input	Rated Input Voltage	12V	Support lithium battery, lead acid battery voltage
	Input Voltage Range	10.2V-15.6V
	Rated Input Current	110A
	Maximum input current	230A	Instantaneous withstanding of impulse current
	No-load current	1000mA
Output	Rated output voltage	225V±5V	Does not support 60HZ/120V output device
	output  frequency	50HZ±1HZ
	Max.power	3000W	1300W For lng time use. 2500W for Instantaneous peak
	Rated Power	1500W
	Conversion efficiency	90%	High efficiency inverter
USB Port	Output	5V/0.6A	For micro/ios/android
8 Protection	Temperature protection	66??/span>	Machine protection when the case temperature is 66 °C
	Output short circuit protection	Protection	Protection
	Input reverse connection protection	Input battery reversed Protection	Will not start the machine
	Input (battery) low voltage protection	10V±0.20V	Fault light on,Buzzer sounds
	Input (battery) low voltage recovery	11.8V±0.20V	Output recovery
	Input (battery) high voltage protection	15.4V±0.20V	Fault light on,Buzzer sounds
	Input (battery) high voltage recovery	15V±0.20V	Output recovery
Display	Green LED	Work indicator	Normal state
	Red    LED	Fault indicator	Lights up when any fault occurs
Size/Weight	261mm×139mm×61mm/1.67Kg



Feature:

--8 Important&Intelligent protection:
?狢ntelligent reverse connection protection
when the wrong operation happends:"+"connected to "-" (X), the machine will not be damaged and will be protected by mechanism.

?﹒ver temperature protection
?﹩ow voltage protection
?Μverload protection
?力ver current protection
?令ver voltage protection
?吁hort circuit protection
??span class='tlid-translation translation' lang='en'>Anti-shock protection

--USB 5V output function.

--High-pre-cision circuit board.

-- Beep alarm prompt mode: reminder fault and misoperation.
Buzzer reminder device.  reminding user through a buzzer reminder.

-- Intelligent silent cooling fan to extend the life of the inverter.

---Universal three-hole socket, strong compatibility,most appliances are suitable.

--Aluminum-mag-nesium alloy casing: lightweight and durable, providing advanced protection against falling and bumps,
good thermal conductivity, can quickly reduce the temperature of components, work long hours are not affected.

--Applicable electrical type display: electromechanical (electric drill), fan household (refrigerator, fan), digital electrical (notebook), light bulb, car use.


Package Inlcuded:
1X Minleaf Power Inverter
1XEnglish Manual
1XUltra-thick Battery Cable

*Tips:
This is not grid inverter.
Risk of high voltage, children away!
